The Active Grow LoPro Max Series Luminaires are lightweight and ultra-thin LED fixtures designed to replace HPS lights in vertical racking or sea of green applications. The LoPro Max features Philips chipsets for maximum light output and proprietary optics that create uniform light coverage and deep canopy penetration for high DLI requirement plants. Each fixture comes standard with Active Grow’s proprietary Entourage Spectrum which incorporates 730 nm wavelengths to increase photosynthesis rates via the Emerson Effect. These additional Far-Red wavelengths boost healthy growth during vegetative and flowering cycles. The natural high CRI 94 light also makes plants look more vivid, helping growers spot pests and fungus like powdery mildew easier. The integrated rotary dimmer provides smooth dimming down to 10%. Growers can also dim multiple fixtures via the daisy chain power and dimming ports using a smart controller. The luminaires are DLC listed, IP65 rated for tough CEA applications and deliver a long lifetime of outstanding and consistent performance.
Specs
Model/SKU: AG/640LPM/ES/277V/YY
Watts: 640
Voltage: 120-277volts, 50-60hz
Amperage: 120V (5.33A) / 208V (3.07A) / 240V (2.66A) / 277V (2.31A)
PPF (light output): 1670 µmol/s
PPF efficacy: 2.56 µmol/J
PBAR output (280-800 nm): 1800 µmol/s
PBAR efficacy: 2.76 µmol/J
CRI: 94
Spectrum: Entourage Spectrum
Lifetime: 50,000 hours
Coverage area:
- Flower- 4' x 4'
- Veg- 5' x 5'
Mounting height: 6-36″ (152-914mm)
Dimmable: Integrated dimmer 10-100% / 1-10V hardwire / Smart controller
Smart controller compatible: Yes
Daisy Chainable: Yes
Daisy chainable dimming: Yes
Daisy chainable power: Yes
Certifications: DLC, UL 8800, UL 1598 Wet-location rated
IP rating: IP65
Dimensions: 45.67’’x43.90’’x2.87’’ (1160x1115x73mm)
Weight: 26 lbs (11.8 kg)
Warranty: 5 Years
Accessories included: 2 Y-hangers, 8.2′ (2.5m) 110V NEMA 5-15P power cord
